Used | Martin - Atomic 3000

Used | Martin - Atomic 3000

Flightcase: No
Accessories: None
Condition: Used

The Atomic 3000DMX is a dimmable strobe by Martin. Flash duration, rate and intensity can be individually controlled for great flexibility and diversity of effects. Six programmed effects are available on channel 4 (in the 4-channel DMX mode only).

PHYSICAL

• Size (without bracket): 245 x 425 x 240 mm (9.7 x 16.7 x 9.5 in)
• Weight: 7.5 kg (16.5 lb)

THERMAL

• Maximum ambient temperature: 40° C (104° F)

CONTROL AND PROGRAMMING

• DMX-512 (1990) control: 1, 3, and 4 channel modes
• Data pinout: 3-pin XLR - pin 1 shield, pin 2 cold (-), pin 3 hot (+)
• Compatible remote controls: Martin MC-1 and Detonator
• Stand-alone control: via N.O. or N.C. SPST switch
• Stand-alone options: selectable flash rate or blinder effect

APPROVED LAMPS

• MAX-15 Strobe lamp, Xenon (200-240 V nominal AC power): P/N 97010307
• MAX-7 Strobe lamp, Xenon (100-120 V nominal AC power): P/N 97010308

AC POWER

• Approved AC power (MAX-7 model): 100 - 120 V nominal, 50/60 Hz
• Approved AC power (MAX-15 model): 200 - 240 V nominal, 50/60 Hz
• Peak current consumption: 33 A
• Typical current consumption (MAX-15, high power mode): 8 A
• AC mains power cable: 14 AWG or 2.5 mm2

FUSES

• Primary fuse: 20 AT / 250 V, P/N 05020040

CONSTRUCTION

• Housing: steel
• Finish: electrostatic powder coating
