Used | Apogee - AE-5 NC [NL4]

€250.00 Excl. Tax
Availability:
Out of stock
Art. code
XC-30.5186

The AE-5NC two-way, bi-amped system is identical to the standard AE-5 except that it utilizes a narrow conical (NC) horn to achieve long-throw/tight-pattern, high frequency dispersion.

  • Low Frequency: One Apogee 12"(305mm) permanent magnet cone-type driver is treated with a waterproofing compound, providing resistance to moisture, and enabling long-term stability of cone resonance and cone mass parameters.
  • High Frequency: One Apogee 1"(25mm) throat composite diaphragm compression driver is treated with Ferrofluid® for greater power handling capability, lower distortion, and control of short-term impedance rise.
  • Dispersion: 60° conical
  • Input Connectors: Neutrik™NL4MP Speakon™ connectors standard.
  • Handles: Four handles designed as an integral part of enclosure (no moving parts).
  • Grille: Powder-coated, diamond-punched steel with acoustic foam covering.
  • Rigging Hardware: Four 12-gauge steel nutplates, mounted two on top and two on bottom, recessed, nominally flush; accepts 3/8"-16 thread (10mm nutplate or Aeroquip Pan fittings optional); nutplates are backed with 12-gauge steel internal brackets.
  • Finish: Textured high-strength black epoxy paint.
  • Enclosure Type: 20° trapezoidal, optimally-vented bass.
  • Cabinet Construction: Multi-ply birch with stainless steel fasteners.
More Information
Brand Apogee
Condition Used
