Used | Apogee - AE-8B

TheAE-8B bi-amped stage monitor features a unique articulated baffle allowing large format components to be contained in a low profile enclosure. The AE-8B is especially effective on large reverberant concert stages.

Driver Complement:

• Low Frequency: One Apogee 15" (381mm) permanent magnet cone-type driver is treated with a waterproofing compound, providing resistance to moisture, and enabling long-term stability of cone resonance and cone mass parameters.
• High Frequency: One Apogee 2" (51mm) horn-loaded compression driver is treated with Ferrofluid® for greater power handling capability, lower distortion, and control of short-term impedance rise.
• Input Connectors: Cannon EP series.
• Compatible Processors: DLC24 Digital Controller.
• Grille: Powder-coated, diamond-punched steel with acoustic foam covering.
• Trim: Protective steel skids on top and bottom edges; powder-coated for durability.
• Rigging Hardware: Two 12-gauge steel nutplates mounted two on top, recessed, nominally flush; accepts 3/8"-16 thread, (10mm nutplate or Aeroquip Pan fittings optional); nutplates are backed with 12-gauge steel internal brackets.
• Finish: Textured high-strength black epoxy paint; other colors optional.
• Enclosure Type: Wedge style, optimally-vented bass, articulated baffle.

Engineering Data:

• Cabinet Construction: Multi-ply birch with stainless steel fasteners.
• Format: Bi-amped/Two-way/Electronically-coupled
• Dispersion: H: 60° x V: 40°
• Frequency Response (1m on axis): 46Hz to 16kHz ± 3 dB
• Max. SPL (@1m): 126 dB cont./ 132 dB peak
• PTML (peak transient mechanical limit): 143 dB
• Sensitivity (1W @ 1m): LF:99 dB/ 100Hz to 1 kHz, HF: 104dB/ 1kHz to 20kHz
• Nominal Impedance: 8 ohms, each driver
• Max. Power Handling: LF: 500W cont./ 2000W peak, HF: 150W cont./ 600W peak
• Dimensions: 19.5"(495mm) W x 21.5"(546mm) H x 26.7"(678mm) D
• Weight: 80lb. (36kg)
