Used | Pioneer - DJM-800

Used | Pioneer - DJM-800

The DJM-800 is a powerful 4 channel 96kHz / 24 bit digital mixer that’s complemented by 61 assignable MIDI control channels. It features 'Harmonic Mixing’, a landmark innovation that detects a track’s key and automatically aligns it to the closest true key, removing inaccuracies created when adjusting the pitch.

The DJM-800 displays a wide variety of effects, such as ‘filter’, ‘sweep’ and ‘crush’ effects through a highpass/lowpass filter, notch filter and bit crusher effect for all line channels.

The effects automatically detect the BPM of the music and sync to the beats. In conjunction with the additional Digital Beat Effects, 50 combinations of effects are possible.

Specifications

• Width 320 mm
• Height 108 mm
• Depth 381 mm
• Weight 8 kg
• S/N Ratio Line 105 dB
• S/N Ratio Phono 88 dB
• S/N Ratio Mic 84 dB
• Crosstalk Line 82 dB
• Distortion < 0.005 %
• Power Consumption 30 W

Master

• Master Balance: Yes
• Stereo/Mono Switch: Yes
• Level Meter Size: 15 segment
• Master Out Attenuator: Yes

Channels

• EQ/ISO: 3 band
• EQ/ISO: Range –26 dB ~ +6 dB
• Rotary Faders: Optional
• Level Meter Type: Individual
• Level Meter Size: 15 segment

Performance Control

• Channels: 4
• Sound Colour FX:
• Crush
• Filter
• Harmonic
• Sweep
• Beat FX
• Chorus
• Delay
• Echo
• Filter
• Flanger
• Pan
• Phaser
• Reverb
• Reverse Delay
• Reverse Roll
• Robot
• Roll
• Trans

Effect/Sampler

• Auto BPM Counter: Yes
• Effect Level & Depth Volume: Yes
• MIDI Global Clock: Yes
• Roll Sampler (Fwd): Yes
• Roll Sampler (Reverse): Yes
• Sound Processor: 32

 Crossfader

• Crossfader Type: Carbon Rail
• CURVE Assignable: Yes
• Field Replaceable: Yes

 Mic

• Mic Connection: Jack, Neutrik Combo.
• Mic EQ: 2 band
• Mic EQ Range: -6 dB ~ +6 dB
• Talkover: 3 Position Switch
• Talkover Attenuator: Yes

 MIDI Info

•  Assignable Controls: 61
• MIDI Out (DIN): 1 (5P DIN)
• MIDI Start/Stop: Yes

 Terminals

Inputs

• 1 MIC (1/4 inch Jack)
• 1 MIC (XLR)
• 1 RETURN (1/4 inch Jack)
• 3 PHONO (RCA)
• 4 S/PDIF Digital (RCA)
• 5 CD/LINE (RCA)

Outputs

• 1 BOOTH (1/4 inch Jack)
• 1 MASTER (RCA)
• 1 MASTER (XLR)
• 1 REC (RCA)
• 1 S/PDIF Digital (RCA)
• 1 SEND (1/4 inch Jack)
