Used | Yamaha D5000

€250.00 Excl. Tax

Availability:
Out of stock

Art. code

XC-33.5134

Within the Benelux*

On used products*

Meet our products

OCC Yamaha D5000

Ham and Noise

less than -76dB
THD		less than 0.007% (1kHz, max. level)
Input/ Number of Channel		2
Input/ Nominal Level		+4dB/-20dB (with level select switch)
Input / Maximum Level		+24dB (nominal level +4dB)
Input/ Impedance		20K Ω
Output/ Number of Channel		2
Output/ Nominal Level		+4dB/-20dB (with level select switch)
Output / Maximum Level		+24dB (nominal level +4dBm)
Output/ Impedance		150 Ω
AD Conversion		20bit, 64Fs over sampling
DA Conversion		20bit, 8Fs over sampling
Sampling Frequency		50KHz
Propagation Delay		2.8 milliseconds
User Program		100
Front Panel / Knob		Input Level, Mix, Data Entry
Front Panel/ Key		Left arrow (Store), Right Arrow (Recall), Up arrow, Down arrow, Program, Utility, Trigger, Bypass, Delay, FB, Mod, Duck, Power
Front Panel/ Display		56 x 128 dot LCD 8-segment LED x 2 (level meter) 7-segment LED x 2 (program no.) Key LED x 8 (Delay, FB, MOD, Duck, Program, Trigger, Utility, Bypass)
Rear Panel/ Connector		Input L,R (XLR x 2, phone x 2) Output L,R (XLR x 2, phone x 2) MIDI In, Thru/Out (DIN 5p x 2)
Rear Panel/ Switch		Input +4dB/-20dB Output +4dB/-20dB Thru/Out (MIDI)
Rear Panel / Jack (Foor SW)		Bypass, Program Inc / Dec, Trigger
Power Requirements		AC120V, 60Hz (US and Canadian models) AC240V, 50Hz (British model) AC230V, 50Hz (General model)
Power Consumption		25W
Dimensions (W x H x D)		480 x 45.2 x 336.4 mm (18-7/8" x 1-13/16" x 13-1/4")
Weight		4.7kg (10 lbs 5.8 oz)

More Information
Condition	Used
Brand	Yamaha
