Used | High End Systems - HOG-3 DP 2000

€600.00 Excl. Tax
Availability:
Out of stock
Art. code
XC-20.0081

The Wholehog DP 2000 DMX processor provides the output power for Wholehog systems. The Wholehog Operating System doesn't limit you to a fixed number of DMX channels - just add as many DP2000 DMX processors as needed (along with an Ethernet switch) to supply the specified number of DMX universes for the production or installation.

Each unit features four insolated, half-duplex DMX512 ports and one Fast Ethernet input for a total channel output count of 2048 per unit on four DMX universes. By utilizing distributed processing and adding processing as needed to your system, the console OS is not significantly affected by adding additional channel output capacity.

  • Four isolated, half duplex DMX 512 outputs (2048 channel total output capacity)
  • Local interface with LCD screen and buttons for configuration and testing
  • DMX status and test facilities
  • All functions are configurable remotely
  • Firmware remotely upgradeable over network
  • 75MHz PowerPC processor with 32Mbyte DRAM and 8Mbyte FLASH memory
  • 100Base-TX fast ethernet
  • White LED backlit graphic LCD for graphical user interface
  • Comprehensive LED status feedback
  • Auto-ranging mains input (90-250V AC)
  • 1U 19" rack unit, 4.5" deep
More Information
Brand High End Systems
Condition Used
