Used | High End Systems - Showgun (2kW)

High End Systems Showgun (type 2, 2000W), a larger than normal automated light that can project images, change and mix dichroic colours, and switch from hard-edge to soft-edge, all within a compact system. Adding an extra bit of flash is the LED Tracking System, which forms a circle around the lens.

Showgun's's main output uses a 2000W short arc metal halide lamp. The MSR 2000SA Gold lamp uses a fast-fit socket design that allows for a more compact reflector combination. Combining the high-performance lamp, advanced reflector and revolutionary optical design, Showgun produces more than 100,000 lumens of output.

Showgun type 2 (2000W)

Features

• Proprietary Short Arc Lamp and optics produce exceptional light output
• Variable soft-edge
• fully rotating, indexable lithos
• Variable iris
• Variable strobe, Electronic strobe
• Light Burst lamp boosting
• Zoom range from 9° – 18°
• Remote focus
• Full optical dimming and fade to black
• Innovative LED Tracking Ring produces over 5000 lumens of RGB color. Homogenously mixed RGB LED circular array eliminates the multiple colored RGB look when white or mixed colors are produced.
• Smooth CMY color mixing provides and infinite palette of color
• Four indexing Litho/Gobo rotators
• Black Light projection filter
• TriColor effect supports independent color flag control
• Tracking and Independent modes selectable via DMX
• Optical encoders automatically correct the head’s position if manually moved

Operation

• 420° pan and 216° tilt movement
• Fixture Output: 100,000 Lumens
• Auto-switching power supply
• Large dot matrix display allows for 2 lines of text
• 200v-240v
• 30 DMX channels
• DMX Connector: 5-pin XLR
• Compliances: ETL, CE

Construction

• Modular construction
• Fast service design for Reflector, Condenser and Output lens
• Electronic cooling system control
• Stunningly fast, smooth and quiet yoke movement using proprietary multi-phase technology
• Performance oriented exterior design prevents stray light scatter
• Pan and tilt locks for easy transportation.

Electrical Specifications/Light Source
Power Consumption: 14 Amps at 208 V, 11 Amps at 240V

Fixture Rated Power: 2800 W

Lamp

Mechanical Specifications:

Fixture Dimensions: mm: 596x639x959 (in: 23.5x25.2x37.8)

Fixture Weight: 63.5kg (140 lbs.)
