Used | L-Acoustics - ARCS II (old color)

€1,600.00 Excl. Tax
Availability:
Out of stock
Art. code
XC-30.5190

Used | L-Acoustics - ARCS II (old color)

The ARCS® II is the full-range element of a constant curvature WST® (Wavefront Sculpture Technology) line source.

The ARCS II loudspeaker enclosure is based on a 2-way active design with a nominal impedance of 8 ohms for both the HF and the LF section. It features one 15’’ neodymium speaker in a bass-reflex tuned enclosure and one 3’’ neodymium diaphragm compression driver coupled to a DOSC® waveguide. The cabinet is made of first grade Baltic birch plywood to ensure maximum acoustical and mechanical integrity.

The ARCS II operates over the nominal frequency range of 50 Hz to 20 kHz. This response can be extended down to 25 Hz with the SB28 subwoofer. The DOSC HF waveguide generates a 22.5° symmetric x 60° asymmetric (-20°/+40°) directivity pattern. These values correspond to the horizontal x vertical coverage angles, for an ARCS II enclosure standing vertically.

The ARCS II rigging system allows assembling a horizontal or vertical array with constant curvature. The DOSC waveguide in the HF region ensure a perfect acoustic coupling between the elements of an array. The WST criteria are fulfilled, so that such an array can be qualified as a true line source. Any WST line source provides a smooth tonal response and a coverage that is free of secondary lobes over the entire frequency range.

The ARCS II is driven and amplified by the LA4X or the LA8 controller with a single factory preset. These ensure system linearization, protection, and optimization for the loudspeaker system.

Including dolly & cover

  • Usable bandwidth (-10dB): 50 Hz - 20 kHz ([ARCS II] preset)
  • Mazimum SPL: 142 dB ([ARCS II] preset)
  • Coverangle (-6 dB): 22.5° symmetric x 60° asymetric (-20°/+40°)
  • Transducers: LF: 1 x 15’’, neodymium, weather-resistant, bass-reflex
    HF: 1 x 3”, neodymium, diaphragm compression driver,
    DOSC waveguide
  • Nominal impedance: LF: 8 Ω
    HF: 8 Ω
  • RMS power handling: LF: 600 W
    HF: 100 W
  • Connectors: IN: 1 x 4-point SpeakOn®
    LINK: 1 x 4-point SpeakOn®
  • Rigging components: Captive coupling bars

Physical data:

  • W x H x D: 439 x 820 x 652 mm, 17.3 x 32.3 x 25.7 in
  • Weight (net): 50 kg, 110 lbs
  • Cabinet: Baltic birch plywood
  • Finish: Dark grey brown Pantone® 426C
  • Front: Steel grill with anti-corrosion coating, Airnet® fabric
  • Protection rating: IP55
  • Rigging components: Steel with anti-corrosion coating
More Information
Brand L-Acoustics
Condition Used
