Used | Apogee - AE-10 SUB

Characterized by a tight and punchy sound, the AE-10 adds depth and dramatic impact to musical passages. When mated with AE full-range loudspeakers, the AE-10 extends low frequency response without muddying or coloring the upper frequencies.

Format:
Single-amped/Electronically-coupled

Dispersion:
Omni-directional

Frequency Response (1m on axis):
38 Hz to 120 Hz ± 3 dB

Max. SPL (@1m):
128 dB cont./134 dB peak

PTML (peak transient mechanical limit):
151 dB

Sensitivity (1W @ 1m):
95 dB/20 Hz to 100 Hz, each driver

Nominal Impedance:
8 ohms, each driver; separate connections to each driver

Max. Power Handling:
1000W cont./3200W peak (500W cont./1600W peak, each driver)

Dimensions:
front: 32"(813mm) W x 22.5"(572mm) H
rear: 25"(635mm) W x 22.5"(572mm) H
depth: 24"(610mm)

Weight:
59.5 kg (131 lb.)
