Used | Apogee - AE-5 [NL4]

Two-way, bi-amped system is the flagship of the Apogee line. This fully arrayable system functions brilliantly when used alone or as a building block for a large sophisticated system, thus making it one of the most versatile loudspeakers ever developed.

• Low Frequency: One Apogee 12"(305mm) permanent magnet cone-type driver is treated with a waterproofing compound, providing resistance to moisture, and enabling long-term stability of cone resonance and cone mass parameters
• High Frequency: One Apogee 1"(25mm) throat composite diaphragm compression driver is treated with Ferrofluid® for greater power handling capability, lower distortion, and control of short-term impedance rise
• Input Connectors: Neutrik™NL4MP Speakon™ connectors standard.
• Handles: Four handles designed as an integral part of enclosure (no moving parts)
• Grille: Powder-coated, diamond-punched steel with acoustic foam covering
• Rigging Hardware: Four 12-gauge steel nutplates, mounted two on top and two on bottom, recessed, nominally flush; accepts 3/8"-16 thread (10mm nutplate or Aeroquip Pan fittings optional); nutplates are backed with 12-gauge steel internal brackets
• Finish: Textured high-strength black epoxy paint
• Enclosure Type: 20° trapezoidal, optimally-vented bass
• Cabinet Construction: Multi-ply birch with stainless steel fasteners

• Format: Bi-amped/Two-way/ Electronically-coupled
• Dispersion: H: 90° x V: 45°
• Frequency Response (1m on axis): 53 Hz to 17 kHz ± 3 dB
• Max. SPL (@1m): 125 dB cont./131 dB peak
• PTML (peak transient mechanical limit): 144 dB
• Sensitivity (1W @ 1m):
• LF: 99 dB/100Hz to 1 kHz
• HF: 106 dB/1kHz to 20kHZ
• Nominal Impedance: 8 ohms, each driver
• Max. Power Handling:
• LF: 300W cont./ 1200W peak
• HF: 150W cont./ 600W peak
• Dimensions:
• front: 14"(356mm) W x 23 "(584mm) H
• rear: 9.3"(236mm) W x 23" (584mm) H
• depth: 16.5"(419mm)
• Weight: 76 lb. (34.5kg)
