Used | dBTechnologies - DVX D10

USED - The DVX D10 is an active 10"/1" two-way speaker cabinet perfect for use in music and speech reinforcement applications demanding true frequency response, balanced dynamic response, and assertive sound pressure levels. Equipped with a high-quality 10” RCF woofer and a 1“ RCF neodymium compression driver with rotatable CD horn, the DVX D10 is fullrangeenabled and can be deployed for many applications without an added subwoofer.
The housing’s multifunctional design incorporates a slanted panel for monitoring, rigging points, and even a special monitor setup controlled by the onboard DSP, which also acts as a controller, providing active equalizer, x-over, limiter, and phase and time alignment functions. Combining the DVX D10 with a DVA series S09 subwoofer creates remarkably powerful yet compact satellite systems.

Acoustical Data

• Frequency Response: [-10dB] 70 - 20.000 Hz
• Frequency Response: [+/- 3dB] 85 - 19.000 Hz
• Max SPL: 127 dB
• HF: 1 "
• Type HF: RCF Neodymium
• Voice Coil HF: Titanium 1.4 "
• Directivity: 90x70 °
• Horn CD: Horn Aluminium
• Rotatable Horn: Yes
• LF: 10 "
• Type LF: RCF Neodymium
• Voice Coil: LF 2.5 "

Amplifier

• Amp Technology: digipro
• Amp Class: Class D
• HF Amp: 200 W
• LF Amp: 400 W
• Cooling: Convection

Processor

• Controller:DSP, 24 Bit/48 kHz
• System Presets: Flat, Monitor
• Limiter: RMS, Peak. Thermal, Multiband
• Crossover Frequency MF-HF: 1600 Hz
• Slope MF-HF: 24 dB/Octave

Input Section

• Signal Input 1 x XLR, fem sym, 1 x 6.3mm jack, sym
• Input Sensitivity [dBu] -00 - max. -3 dBu
• Signal Output 1 x XLR male, sym, 1 x 6.3mm jack, sym.
• Power Socket: Powercon In
• Voltage Range: 240 V

Mechanics

• Housing: Multiplex birch plywood
• Housing Design: Multifunctional
• Color: Black
• Surface Texture: Textured acrylic lacquer
• Handles: 1 x on top
• Pole Mount: 36mm
• Angles Up: Monitor use 45 °
• Front Grille: 1.5mm metal backed with acoustic foam rubber
• Rigging Points: 6 x M8, 2 x 10mm Quick Release for DTF-bracket
• Flytracks: 2 x on top, 2 x on bottom
• Width: 290 mm (11.6 in)
• Height: 510 mm (20.4 in)
• Depth: 310 mm (12.4 in)
• Weight: 11 kg (24.25 lbs)
