Used | L-Acoustics - KARA (old color)

Used | L-Acoustics - KARA

Condition: Good
Flightcase: Not included
Accessoiries: -
Extra information: Featuring the old L-Acoustics color

With a design inspired by the K1 stadium system, KARA^® delivers the highest performance, featuring a compact and lightweight enclosure complying with rigging and sightline constraints and the complementary SB18(i) subwoofer for reinforced LF contour applications.

KARA^® delivers a considerable number of improvements over the previous generation of line sources: added LF resources for increased bandwidth and coherence, improved directivity control in the horizontal plane, vertical coverage capability and integrated rigging system.

With a horizontal directivity of 110° and a vertical inter-element variation up to 10°, KARA^® is fully configurable to match any audience geometry. Utilizing the unrivaled characteristics of WST^®, KARA^® delivers clarity, precision and a unique proximity effect offering the audience an incomparable listening experience.

The LA-RAK touring rack and LA8 amplified controller preset library deliver an extremely advanced and precise drive system for KARA^®. A wide range of system configurations to accommodate various LF contour requirements and integration constraints are available for the sound designer and system engineer for a high level of creative freedom.

• Usable bandwidth (-10dB): 55 Hz - 20 kHz ([KARA] preset)
• Norminal directivity (-6dB): Horizontal: 110° symmetric
  Vertical: Dependent upon number of elements and line source curvature
• Maximum SPL: 141 dB ([KARA] present)
• RMS handling capacity: LF: 450 W
  HF: 80 W
• Components: LF: 2 x 8" neodymium weather-resistant
  HF: 1 x 3" neodymium diaphragm compression driver
  Nominal impedance: LF = 8 ohms, HF = 8 ohms
• Rigging: Steel, certified for: 24 KARA (BGV-CI compliant)
  Angle increments: 0, 1, 2, 3, 4, 5, 7.5, 10°

Physical data:

• W x H/h x D: 730 x 250/164 x 482 mm, 27.7 x 9.8/6.4 x 19 in
• Weight (net): 26 kg, 57.2 lbs
• Connectors: 2 x 4-point SpeakON^®
• Material: Baltic birch plywood
• Finish: Dark Grey brown PANTONE^® 426C
• Front: polyester powder-coatied steel grill
  Airnet^® acoustically neutral fabric
• Rigging: steel with dual coating zinc and polyester powder
