Used | Martin - Cyclo 04 TL Fixture

he Cyclo Series is a range of controllable, fluorescent color changers. These fixtures are designed to be used for cove lighting, perimeter lighting, light walls, behind semitransparent materials, or any place where room is restricted. Cyclo is a family of fixtures based on dimmable fluorescent T5 tubes. The T5 tubes have achieved widespread popularity due to their sleek design and high efficacy combined with their long lamp life.

CYCLO 04 Cyclo 04 contains dimmable red, green, blue and white tubes.

PHYSICAL

L x W x H . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1190 x 98 x 88 mm (50 x 4 x 3.7 in)

Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5.5 kg (12.1 lbs)

Fixture color . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . white (NCS 0402-G06-Y)

INSTALLATION

Orientation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . any

Minimum free space around fixture when installed . . . . . . . . . . . . . . . . . . . 25 mm (1 inch)

SOURCE

Approved lamp type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .OSRAM T5 FH 28 watt tubes

Light source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . T5 tubes (3x28W)

Expected lamp life. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20000 hours

POWER

AC power. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 198 V - 254 V, 50 / 60 Hz

Dimmer control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . , 1-10V control

Maximum power and current @ 230 V / 50 Hz . . . . . . . . . . . . . . . . . . . . 0.56 A / 128 watts

THERMAL

Maximum ambient temperature (Ta). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40° C (104° F)

DYNAMIC EFFECTS

Dimmable tubes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Red, green, blue and white

Independent dimming of each tube via 516 Converter

CONTROL (VIA 516 CONVERTER)

Number of independently controllable dimming channels . . . . . . . . . . . . . . . . . . . . . . . . .16

Channels required per independently controlled Cyclo 02 group . . . . . . . . . . . . . . . . . . . . .2

Channels required per independently controlled Cyclo 03 group . . . . . . . . . . . . . . . . . . . . .3

Channels required per independently controlled Cyclo 04 group . . . . . . . . . . . . . . . . . . . . .4

Number of Cyclos per group (fixtures wired in series) . . . . . . . . . .1-10 (of the same model)
