Used | Robe - Club 600 moving head (incl. ½ flightcase)

Used - Robe - Club 600 moving head.

Buy 2 pieces to receive a free flightcase for 2pcs Club 600.

Power supply

• Voltage: 208/230/240V AC, 50/60Hz ~
• Fuse: T 6.3A@230V

Lamp: Philips MSR 575/2 or Osram HSR 575/72

Colours

• Colour wheel 1: - 9 dichroic filters + open
• Colour wheel 2: - 6 dichroic filters,3200 K and 5600K CT filters,UV filter + open

Static gobo wheel

• 9 metal gobos plus an open position, outside diameter=26.9mm, image diameter=22.5mm, aluminium, thickness=0.5 mm
• Gobo shake

Rotating gobo wheel

• 6 glass gobos (1 effect-glass gobo, 3 black and white gobos,1 multicolour and 1 dichroic gobo)
• Gobo indexing and rotation in both directions at different speeds
• Gobo carousel cont. rotation
• All rotating gobos are easily replaceable
• Gobo dimensions: outside diameter = 26.8mm, thickness = 1.1mm, high temperature borofloat or better glass, image diameter = 22 mm
• Effect-glass gobo: outside diameter = 26.8 mm, max.thickness = 4mm, high temperature borofl oat or better glass

Strobe

• Strobe effect with variable speed (max.10 flashes per second)

Dimmer

• Smooth dimmer from 0 - 100 %

Prism

• 3-facet-prism rotating in both directions at different speeds

Focus/Zoom

• Remotely controllable via DMX
• Motorized multi-step zoom (15°,18°,22°)

Iris

• Motorized (steplessly adjustable) iris for different beam diameters

Motors

• 16 high quality stepping-motors controlled by microprocessors

Electronics

• Addressing, special functions setting, effects calibration via control panel with 4-digit LED display
• Readout fixture and lamp usage, receiving DMX values, temperature, etc
• Built-in analyzer for easy fault finding, error messages
• Remotely switching of the lamp
• Bilt-in demo sequences
• Silent fans cooling, remotely controllable speed of fans
• Self-resetable thermo-fuse
• Master/slave operation
• Stand-alone operation
• Digital serial input DMX-512
• 3 DMX modes (14 or 16, control channels)

Pan/Tilt

• Pan movement range 530°
• Tilt movement range 280°
• 8 or 16 bit movement resolution
• Automatic Pan/Tilt position correction
• Remotely controllable speed of pan/tilt movement for easy programming
• Movement control: tracking and vector

Rigging

• Mounting points: 4 pairs of 1/4-turn locks
• Mounting horizontally or vertically via 2 Omega brackets
• Safety chain/cord attachment point

Temperatures

• Maximum ambient temperature: 40° C
• Maximum housing temperature: 80° C

Minimum distances

• Min. distance from flammable surfaces: 0.7m
• Min. distance to lighted object: 2.0m
